Outside pipe diameter: Ø1016 mm
wall thickness and weight
| Inside diameter [mm] | Wall thickness [mm] | Weight [kg/m] |
|---|---|---|
| Ø1008.0 | 4.0 | 99.8 |
| Ø1007.0 | 4.5 | 112.0 |
| Ø1006.0 | 5.0 | 125.0 |
| Ø1005.0 | 5.4 | 135.0 |
| Ø1005.0 | 5.6 | 140.0 |
| Ø1003.0 | 6.3 | 157.0 |
| Ø1002.0 | 7.1 | 177.0 |
| Ø1000.0 | 8.0 | 199.0 |
| Ø998.4 | 8.8 | 219.0 |
| Ø996.0 | 10.0 | 248.0 |
| Ø994.0 | 11.0 | 273.0 |
| Ø991.0 | 12.5 | 309.0 |
| Ø987.6 | 14.2 | 351.0 |
| Ø984.0 | 16.0 | 395.0 |
| Ø981.0 | 17.5 | 431.0 |
| Ø976.0 | 20.0 | 491.0 |
| Ø971.6 | 22.2 | 544.0 |
| Ø966.0 | 25.0 | 611.0 |
| Ø960.0 | 28.0 | 682.0 |
| Ø956.0 | 30.0 | 729.0 |
| Ø952.0 | 32.0 | 777.0 |
| Ø944.0 | 36.0 | 870.0 |
| Ø936.0 | 40.0 | 963.0 |
| Ø926.0 | 45.0 | 1078.0 |
| Ø916.0 | 50.0 | 1191.0 |
| Ø906.0 | 55.0 | 1303.0 |
| Ø896.0 | 60.0 | 1415.0 |
| Ø886.0 | 65.0 | 1524.0 |
