Description

Bernoulli equation is the most important equation for engineering analysis of flow problems. You can resolve many practical tasks by the direct implementation of the Bernoulli equation.

With this calculator, you can calculate flow parameters like pressure, velocity, height, and diameter at any point of a stream if you know parameters in some other point of a stream.

Registration and subscription

Select a subscription plan and enable the full service:

  • Switch between metric and imperial units in one click
  • Export calculation results in Word .docx or Excel .xlsx format
  • Preview results on one place and copy/paste it in your favorite text editor
  • Send results back to your email
  • Support the future of this project

And even more... Subscribed users have access to the full set of 19 calculators available as Java™ Web start application or download Windows™ 64bit application.

Subscribe

Full year service

Monthly cost
$250/month

Full year service $29.95/year

Action
Calculation setup
Press what to calculate
Conditions at position one
Dimensions at one
Flow rates
Conditions at position two
Dimensions at two
Fluid properties

Exclusive calculator

On exclusive calculator page you can use the online calculator without interference from advertisements, additional text, links and other content that is not required for the calculations themselves. A pure experience of using a calculator as with a desktop application.

An exclusive version of the calculator is available to registered users. Choose the right subscription duration and start using the exclusive service.

Exclusive

Description

p1 – pressure in position one
Static pressure of fluid in the point in which flow parameters are known – referent position
p2 – pressure in position two
Static pressure of fluid in the point in which flow parameters should be calculated
D1 - diameter in position one
Internal pipe or stream diameter in the point in which flow parameters are known
D2 - diameter in position two
Internal pipe or stream diameter in the point in which flow parameters should be calculated
V1 - velocity in position one
Flow velocity where flow diameter is D1 and where flow parameters are known
V2 - velocity in position two
Flow velocity where flow diameter is D2 and where flow parameters should be calculated
z1 – height in position one
Height or elevation of the fluid stream in the point in which flow parameters are known
z2 – height in position two
Height or elevation of the fluid stream in the point in which flow parameters should be calculated
q - volumetric flow rate
Fluid flow rate in terms of units of volume per unit of time. Considered to be constant
ṁ - mass flow rate
Fluid flow rate in terms of units of mass per unit of time. Considered to be constant
ρ - fluid inlet density
Density of fluid in terms of mass per unit of volume. Considered to be constant
Δp - pressure drop
Pressure difference between two points of stream line

Calculation setup

Select value to calculate. You should enter not selected one.
p2
calculate pressure in position two
z2
calculate height in position two
v2
calculate velocity in position two
Available only if "use flow rate q in the calculation" is selected. You should enter values for not selected one.
v1
calculate velocity in position one
D1
calculate diameter in position one
q
calculate flow rate
Available only if v2 calculation is not selected. You should enter values for not selected one.
v2
calculate velocity in position two
D2
calculate diameter in position two

Why you should use this calculator?

Use this calculator to easily calculate how:

Stream properties are going to change when flow conditions are changing,
Static pressure is going to change when fluid flows through pipes with different internal diameters,
Pressure is going to change when flowing fluid changes its elevation,

Calculator description

Bernoulli equation is the most important equation for engineering analysis of flow problems. You can resolve many practical tasks by the direct implementation of the Bernoulli equation.

The equation represents the balance of fluid energy associated with its static energy (pressure), kinetic energy (velocity) and energy of the height of the fluid (gravity).

Bernoulli equation

Every single member, in Bernoulli equation on the left side of the above equation, represents specific energy contained in the unit of mass in the fluid stream. The first member is static energy (pressure), the second one is the kinetic energy (velocity), and the third one is potential energy (gravity). The constant on the right side of the above equation means that the sum of all three members is constant at any point in the fluid stream.

This behavior is Bernoulli's principle that states that when flow velocity is increasing, static pressure or potential energy is going to decrease.

Bernoulli's principle has application in wing design where the shape of a wing makes flow velocity change. As a result, a pressure difference is created on the upper and bottom surface area of the wing, resulting in the force pointing up, for airplanes (lifting up the plane), or down for racing cars (adding to the gravity in additional downforce for better grip).

How is the calculation executed?

With this calculator, you can calculate flow parameters like pressure, velocity, height, and diameter at any point of a stream if you know parameters in some other point of a stream.

The point of streamline where stream parameters are known is marked as position one (left side of the calculator), and the point in which you want to calculate stream parameters is marked as two (right side of the calculator). Parameters in point two that you can calculate are:

Pressure
Flow velocity
Stream diameter
Height (geodetic position)

If you select to use volume flow rate in calculations, you can select to calculate between:

Flow velocity at the start of a stream
Flow diameter at the start of a stream
Volume flow rate

When is this calculator not relevant?

This calculator is only valid for inviscid flow and non-conducting fluid flow.
